Collared Eyebolt BS4278 – Metric Thread

Call for price - Guide Price

About the Collared Eyebolt BS4278 – Metric Thread:

Collared Eyebolts – Metric

Please contact us for further details:

Add to Quote

Description

About the Collared Eyebolt BS4278 – Metric Thread:

Collared Eyebolts – Metric

Material: BS970-‐080A27 hardened and tempered
Safety Factor: MBL equals 5 x SWL
Standard: BS4278 -‐ table 1 -‐ 1984
Finish: Self colour
Certiﬁcate: This product is supplied with an EC declaration of conformity, upon request a certifcate of basic raw material
Note: Electro galvanised (zinc plated) also available ‐ prices on request

Safe	Thread	Diameter	Diameter	Diameter	Thickness	Height	Thread	Product	Weight
Working	Size	Base	Eye	Eye	Collar		Length	Code	Each
Load			Outside	Inside
	a	b	c	e	f	g	h
tonnes	mm	mm	mm	mm	mm	mm	mm		kg
0.1	6	22	33	15	7	36	18	CE06M	0.06
0.15	8	22	33	15	7	36	18	CE08M	0.06
0.25	10	22	33	15	7	36	18	CE10M	0.06
0.4	12	22	33	15	7	36	18	CE12M	0.06
0.5	14	29	44	20	10	48	23	CE14M	0.15
0.8	16	29	44	20	10	48	23	CE16M	0.15
1	18	36	52	24	12	58	28	CE18M	0.27
1.6	20	40	59	27	14	65	32	CE20M	0.38
1.6	22	45	64	30	14	73	35	CE22M	0.54
2.5	24	52	77	35	17	84	40	CE24M	0.85
2.5	27	58	85	39	20	94	46	CE27M	1.13
4	30	65	96	44	22	106	51	CE30M	1.62
4	33	72	106	48	24	117	56	CE33M	2.37
6.3	36	81	118	54	27	131	63	CE36M	3.12
6.3	39	86	123	57	29	137	67	CE39M	3.81
8	42	101	148	68	34	164	79	CE42M	6.27
8	45	101	148	68	34	164	79	CE45M	6.45
10	48	101	148	68	34	164	79	CE48M	6.51
12.5	52	115	168	76	38	186	89	CE52M	9.58
16	56	128	188	86	43	208	100	CE56M	12.99
20	64	144	212	96	48	234	112	CE64M	18.20

***For sizes M56 and M64 please call for prices

View our full ange of lifting eyes here

Additional information

Weight	N/A
Size	CE06M, CE08M, CE10M, CE12M, CE14M, CE16M, CE18M, CE20M, CE22M, CE24M, CE27M, CE30M, CE33M, CE36M, CE39M, CE42M, CE42M, CE48M, CE52M
